Stainless Steel Crank Shaft
Material:Shaft
brass flange nut
Material properties
Brass material: Brass is an alloy composed of copper and zinc. Its main component, copper, has good electrical and thermal conductivity. In the application of nuts, this feature helps to conduct heat better in some connection parts that require heat dissipation. At the same time, the chemical properties of copper are relatively stable and not easy to rust in normal environments. The addition of zinc increases the strength and hardness of brass, making it more suitable than pure copper for making mechanical parts such as nuts.
Corrosion Resistance: Brass flange nuts have excellent corrosion resistance. It resists oxidation and chemical corrosion in many industrial environments and outdoor installations. For example, in air containing a certain amount of humidity or in a slightly acidic environment, a dense oxide film will form on the surface of brass, which can prevent further corrosion. This characteristic makes brass flange nuts widely used in some fields such as pipeline systems and marine equipment that require high corrosion resistance (such as some non-critical parts of ships that require corrosion resistance).
Structural features
Flange structure: The flange is the key structural part of the brass flange nut. The flange portion is usually larger in diameter than the body portion of the nut and is flattened around one end of the nut body. The main function of this flange is to increase the contact area between the nut and the connected parts. The flange distributes the pressure more evenly when tightening the nut, preventing the surfaces of the connected parts from being crushed. For example, when connecting softer materials (such as plastic pipes or thin metal plates), the presence of flanges can effectively protect the material surface and avoid deformation or damage due to excessive local pressure.
Thread structure: The thread structure inside the brass flange nut has high precision. The thread profile, pitch and other parameters all meet the corresponding standards to ensure a tight fit with the bolt or screw. The machining accuracy of threads is crucial to the reliability of nut connections. In practical applications, precision threads can reduce the possibility of loosening and can withstand large axial forces and torques.
Manufacturing process
Casting process: Some brass flange nuts are manufactured by casting process. During the casting process, molten brass alloy is poured into a specific mold, where it cools and solidifies to form the blank of the nut. The casting process can produce nuts with complex shapes and allows a certain degree of control over the internal structure of the nut. However, cast nuts usually require further processing, such as machining, to improve their accuracy.
Forging process: The forging process can make the brass flange nut obtain better mechanical properties. Through forging, the internal structure of brass is denser, and its strength and toughness are improved. The forged nut also needs to go through machining processes such as turning, drilling, and tapping to obtain precise size and shape. This process is often used to manufacture brass flange nuts that require higher strength, such as nuts used in some pipe connections that are subject to greater pressure or vibration.
Machining process: Whether casting or forging process is used, brass flange nuts need to be machined to perfect their structure. Mechanical processing includes turning and smoothing the flange part to make the flange surface smooth and accurate in size; tapping or rolling the threaded part to ensure the accuracy of the thread. During the machining process, appropriate tools and cutting parameters need to be used to ensure the quality of brass nuts.
Piping systems: Brass flange nuts are widely used in piping systems. In plumbing pipes, it can be used to connect various water pipes (such as copper pipes, stainless steel pipes, plastic pipes). Due to its good corrosion resistance, it ensures the long-term stability of pipe connections. Brass flange nuts are also used in some non-critical parts of gas pipelines (such as branch pipe connections). The reliable connection between them and the pipeline can prevent gas leakage.
Machinery manufacturing and equipment maintenance: In the field of machine manufacturing, brass flange nuts can be used to connect various parts of the machine. For example, in some small mechanical devices, it can be used to connect the fuselage and shell, different mechanical transmission components, etc. During equipment maintenance, brass flange nuts are also relatively easy to obtain and replace, and their good adaptability can be used with a variety of bolts to facilitate maintenance personnel to quickly complete equipment repair work.
Electrical equipment: Due to the good conductivity of brass, brass flange nuts are also used in ground connections or low-voltage electrical connections in some electrical equipment. It can be used as a component to connect electrical components and grounding devices, or to connect some electrical lines that require certain conductivity and need to be reliably fixed.
-
Material: Brass
Maximum diameter: 500 (mm)
Maximum length: 10000 (mm)
Tolerance: ±0.01 -
